ANL / CNN_E - Fuse 350A/80V - M8
TBS-5097557-2
ANL / CNN_E Fuse 350Amp
- Battery voltage up to 80V, fuse protection 350Amp
- Mounting M8, hole spacing 61.7mm
- 2 pieces
ANL / CNN_E fuse 400Amp
ANL / CNN fuses are suitable for protecting high currents. We only recommend them up to 400Amp. As most installations in this power range today are lithium batteries, we recommend Class-T fuses for higher currents. Here the fusible element is encapsulated in sand and cannot cause a fire hazard when melting. Short-circuit currents in lithium batteries can be very high. Mega fuses are also suitable for smaller loads.
TBS-5097557-2
Data sheet
- Connections
- M8
- Protection
- 350A
- Dimension
- 81 x 20mm
- Fuse type
- ANL
- System voltage
- up to 80V
Specific References
- EAN13
- 8721042601155
