TBS - DCM 1xM10 single support point (set of 2)
DC Modular single support point M10 in a set of 2
- Single distribution board for DC direct current distribution
- Can be extended with link plates
- High M10 screws, cover can be adapted
DC Modular single support point M10 - set of 2
The single and double insulated DC Modular studs are ideal parts for extending cables, adding branches or forming end points.
The solid and compact design as well as the possibility of connecting several busbars and relays to a fixed grid make these products the best choice for all professional DC power supply systems
The high current busbars are available with M8 or M10 stud sizes.
Features
- Stainless steel bolts, nuts and washers for optimum corrosion resistance
- Tin-plated, high-purity copper busbar provides maximum conductivity, reduces heat and improves efficiency
- Special fiber-reinforced base material offers excellent high-temperature properties, good chemical resistance and high strength
- Unique grid-optimized layouts enable space-saving arrangements of multiple products
- Common connection heights for easy combination of multiple products using connection plates
- Robust transparent covers with cut-outs for cable access from any direction
- Intelligent connector design enables double mirrored cable lug connections
- Easy access to the connections in the system thanks to top-locking covers
The optional adapter plate allows a mixture of high and low current cables to be connected to the same stud.
Data sheet
- System voltage
- bis 60VDC
- Connections
- M10
- Number of outputs
- 1
- Dimension
- DMC Mesh size
- 1 x 3
